Fire-Rated Doors & Frames Fireframes® Heat Barrier Series doors and frames combined with Pilkington Pyrostop® glass provide a barrier to radiant and conductive heat transfer. Fabricated in the United States, the system allows full-lite fire doors for aesthetic or security reasons. “We specified a product that also allowed us to install the largest size of glass we could get with minimal framing.” -David Steele, Muller and Muller Doors available in single leaf or double leaf design Modular system that can incorporate 60/90 minute full-lite temperature rise doors Can incorporate large individual panes of Pilkington Pyrostop® glass Passes positive pressure test standards UL 10C Frames supplied "K-D" (knock-down, or welded upon request) Unrestricted glazing area for use in locations where total glazing exceeds 25% of wall area Durable steel frames ensure low maintenance system Hardware available to fit functional requirements.

Check with TGP for compatibility Finish painted at the factory to match desired color scheme Fabricated in the U.S.A. Brushed stainless steel finish available (doors only) Maximum Allowable Size Information 90 Min. (Transom Only) 60 to 90 Min. All door hardware for Heat Barrier Series doors is supplied by Technical Glass Products. Please contact Technical Glass regarding your individual hardware requirements. Standard door hardware package may include: Classified and labeled by Underwriters Laboratories, Inc.® and Underwriters Laboratories of Canada. File number for labeled 60/90/120 minute fire-rated assemblies is R-19207, design U533. Frame tests performed in accordance with ASTM E119, CAN/ULC-S101, NFPA 251, UL 263, UL 9, and UL 10C. Door tests performed in accordance with UL 10B, UL 10C, and NFPA 252. Approved for use in New York City, MEA#240-00-M. Approved for use in Los Angeles: LARR 25798. The time, in minutes or hours, that materials or assemblies can be expected to prevent flames and smoke from spreading.

As heat develops within the source area, pressure within the enclosed room begins to build relative to the pressure outside. Once the fire reaches equilibrium in the positive pressure zone, smoke, hot gases and flames are forced through any openings in the door or window assembly. Testing to the UL 10C standard more closely simulates real fire conditions. Blocks radiant and conductive heat transfer from one side of the glass to the other. A required characteristic of glass used as a wall. Classified and labeled by Underwriters Laboratories, Inc.® (UL), an independent product safety certification organization. Immediately following a furnace test, heated glass is subjected to water from a fire hose. The cooling, impact and erosion created by the hose stream tests the integrity of the glass. In the U.S., the hose stream test is required for all fire ratings over 45 minutes (all fire ratings require it in Canada). Available in stainless steel frame finish options for increased design flexibility.

The amount of force glass can be expected to withstand. Testing simulates different levels of impact, from that of a small child to a full grown adult. FireLite IGU is a fire-rated insulated glass ceramic unit that also complies with energy codes. windows and doors bowling green kyIt is designed for use in exterior applications where energy codes require an insulated product, or for interior applications with special needs such as sound reduction.overhead door remote for legacy Withstands continuous temperatures to 1292° F for use in high efficiency heating appliances.front door lock lowes The ability of glass ceramic to withstand sudden heating, cooling, or both without cracking, shattering or exploding out of the frame.windows and doors burlington vt

The ability of the glass to stop various types of ammunition. Ratings are assigned in levels from 1 to 8, with a Level 8 rating being the highest (able to stop a 7.62mm rifle lead core full metal copper jacket, military ball).how much do garage door torsion springs cost The capacity of an element in a building structure to support a weight in addition to its own.interior glass doors soundproof by Abu Dhabi Ajman Al Ain Dubai Fujairah Sharjah Sort by Relevance A-Zpatio door repairs melbourne Door is a movable barrier opening, closing or separating an entrance, to a room, cupboard or vehicle. Doors may help control the physical atmosphere, effectively helping in holding the warmth or coolness from escaping from the enclosed area.

They are important in setting in a feeling of privacy. Fire rated doors help by preventing fire from spreading, doors also act as a noise blockade by being sound proof. Doors are set on hinges or else slide or spin within the allocated space designed for them. Doors separate rooms and closets and can vary in shape and size, length and width. Doors are usually made of wood, metal, glass etc. depending on the usage. Doors now come in diverse designs, from sliding doors to French doors to rotating doors.Features:  • Patented top latching mechanism interlocks door to frame  • Strong, durable construction for a high level of security  • Adjustable steel rods protected in contoured covers  • Easy to install  • Clean, unobtrusive design  • Pushbar clad or anodized, not plated, in a variety of finishes  • Also available in top rod only version Specifications: 3100 Series Certifications:• UL Panic-Fire Exit Hardware, up to 3 hrs• UL 305 Panic Hardware• California State Fire Marshall• New York City MEA*• Warnock/Hersey Listing

8100 Series Certifications:• UL 305 Panic Hardware• ANSI/BHMA A156.3 Grade 1• California State Fire Marshall• New York City MEA* *Consult Factory for specific number Materials: Pushbar made of extruded aluminum, clad or anodized in a variety of finishes. Handing: Device is non-handed. Lever Entry Trim is field reversible. Pushbar Length: Standard sizes: dimensioned for 30”, 36”, 42”, and 48” openings. Standard width bars can be field cut to the next smallest opening width. Bar Height: Standard model adjusts from 30” to 44”. Door Height: Standard model fits up to 8 ft door, with bar height at 40”– 44”. For doors up to 10 ft. Tall Door Kit available separately: 8055 Tall Door Kit for 8100 or 3055 Tall Door Kit for 3100. Door Thickness: Suits 1-3/4” standard, up to 2-1/4”. Stile Width: 3100 – Minimum 3-3/4”. Door construction may require additional stile width to meet fire ratings and provide adequate strength.

8100 – Minimum 3-3/4”. Projection: 2-15/16” when fully projected, 1-15/16”when dogged. Dogging: Standard dogging with hex key or optional cylinder dogging for 8100 Series only. Electric dogging also available for 3100 and 8100 Series. Fasteners: Standard self-tapping screws. Optional Sex Bolt Kits 26-0584 (two required per device). Cylinders (available separately): See CYLINDERS for cylinder make, thumbturn and trim ring information. Cylinder x Fixed Pull: (ANSI/BHMA Function 03): Accepts any standard Rim cylinder. 3080 Entry Trim (ANSI/BHMA Functions 08, 09): Accepts any standard diameter Mortise cylinder with MS cam. Accommodates cylinder lengths from 1” to 1-1/4”. Bolts and Strikes: The patented top latching mechanism utilizes a rotating top bolt which deadlatches around the header strike, interlocking the door to the frame. For wood frames, an additional plate is supplied for securing the header strike. The hexagonal, hardened steel bottom bolt is shielded in a cast housing for strength and stability.

Top Rod Only: The surface vertical rod exit device is also available with a single vertical rod on top. Specify by adding “T” after exit device number. Options and Accessories:Silent Electrification Motorized Latch Retraction: The SE Motorized Latch Retraction option provides near-silent operation for quiet environments such as hospitals, offices, hotels, and libraries where solenoid-driven devices would be disruptive. Electric Latch Retraction: The LR option uses a solenoid mounted in the pushbar for instantaneous unlocking and locking of the exit device from a remote location or access control device. LR Option is not available on rim type exit devices (see EL option). Alarmed Exit Device: This battery-operated option emits a loud (95 decibel) alarm to notify management of unauthorized exit. Available on minimum opening width 36". Cannot be ordered with other exit device options. Request to Exit (REX) – Monitor / Signal Switch: Mounted in the exit device pushbar on the hinge end, the switch can be used to activate signal light, horn, monitor, or other devices.

Cylinder Dogging: For management control of dogging exit devices for life-safety exit devices only. Electric Dogging: A holding magnet keeps the pushbar depressed (set manually) and the latch retracted for lower profile exit devices, resulting in less damage and quieter operation. Matching End Caps: Matching end caps are available for applications where it is preferable that the end caps match the finish of the exit device. Available for US finishes only. Available Finishes: 313 Dark Bronze Anodized, 335 Black Anodized, 628 Clear Anodized, US3 Bright Brass, US4 Satin Brass, US32 Bright Stainless, US32D Satin Stainless. For more information on any of the options and accessories listed above please see Options & Accessories for Exit Devices. Related Products: When purchasing this product, please consider the following related products, available separately: Optional Sex Bolt Kits 26-0584 (two per device) available separately. Tall Door Kit available separately: 8055 for 8100 or 3055 for 3100.
