Republic offers a complete line of standard masonry (ME Series) and drywall (MH Series) frames to fit any of your architectural needs. ME Series Universal Frames and MH Series Drywall Frames are constructed to conform to Steel Door Institute Standard ANSI A250.8-1998 (SDI-100). ME Series shall be formed from 16, 14, or 12 gauge cold-rolled steel or galvanealed steel. MH Series Frames are formed from 16 or 14 gauge cold-rolled steel or galvanealed steel. (14 gage maximum height of 8’0″). Frames may be either knocked-down or have corners welded and ground smooth. All frames have aligning tabs and slots for secure and easy interlocking of jambs to head. Frames are provided with 9/32″ DIA. silencer preparation, (3) per strike jamb and (2) per head for double openings for field application after finish painting. Frames for 1 3/4″ (44) doors have 9 gage steel universal hinge tap plates projection welded with provisions for 4 1/2″ (114) template type hinges and 14 gage steel strike reinforcement plate, extruded and formed to the equivalent of 10 gauge, projection welded with provision for a Universal ANSI A115.1 or ANSI A115.2 strike.

Frames for 1 3/8″ (35) doors have 11 gage steel hinge reinforcement plates projection welded with provisions for 3 1/2″ (89) template type hinges and 14 gage steel strike reinforcement plate projection welded with provision for cylindrical ANSI A115.2 strike.4 door jeep wranglers for sale in ga ME Series Universal Framesused commercial storefront glass doors for sale Republic offers a complete line of flush frames that are available in 16, 14, and 12 gauge cold-rolled or A60 galvanealed steel. london bi fold door companyFrames can be knocked down or set up and welded at miters and ground smooth. frameless shower doors mission viejo

Republic 12 gauge frames are butt end welded or bolted corner connection only.car window repair davie fl All Republic frames are available for either 1-3/8″ or 1-3/4″ thick doors. shower door spares ebayRepublic ME series universal steel frames are manufactured for all wall conditions such as masonry, steel stud, wood stud, and poured concrete.car door moulding tape Republic offers several different frame types. Each type has certain characteristics that fulfill either installation or esthetic requirements of an opening. Certain types of frames have been developed to accommodate special hardware. Others have been developed through necessity, to satisfy Federal and local building and fire code requirements.

ADDITIONAL ME FRAME TYPES AVAILABLE: 2 and 3 Way Corner Posts Wrap around masonry (Block or Pre-poured) TYPICAL WALL & BASE ANCHORS: One Piece Welded Based Anchor For more information please visit Windsor Republic’s Website MH SERIES DRYWALL FRAMESSpecifiers Tech Tips Library - Doors and Windows 08 1000 - Doors and Frames 08 1050 - Door Accessories 08 1100 - Metal Doors and Frames 08 1110 - Steel Doors and Frames 08 1118 - Residential Steel Doors 08 1119 - Wrought Iron Doors 08 1120 - Aluminum Doors and Frames 08 1125 - Interior Aluminum Doors and Frames 08 1130 - Stainless Steel Doors and Frames 08 1140 - Bronze Doors and Frames 08 1160 - Accordion Fire Doors 08 1170 - Window and Door Security Bars and Grilles 08 1180 - Screen & Storm Doors 08 1400 - Wood Doors 08 1420 - Commercial Wood Doors 08 1426 - Plastic-Laminate-Faced Wood Doors 08 1480 - Residential Doors (and light commercial)
