Meticulous attention to detail coupled with unparalleled German engineering continues to earn cred in the design industry. We’re located in South Florida in Dania Beach, conveniently between Miami and Fort Lauderdale. Send this to friendYour emailRecipient emailBefore the instructions, there are just a few things to keep in mind before beginning. 1. The door itself should be at least 1-2″ wider on the side of each opening. 2. Make sure the track is level during installation. 3. Are the holes pre-drilled? If not, you need to make sure to locate the studs and drill through the track. The standard set of hardware works with doors of 1 1/4”-2” thickness. 1. Place hanger on the top and front of the door. Insert 2 1/2” placeholder into the groove (use cardboard from box). 2. Position hanger desired distance from edge of door (we recommend 2” from side of door or centered in stile) 3. Place a square to the hanger, and mark the holes. 4. Remove strap, drill a 3/8” clearance hole through the door on the markings previously made.

5. Remove wood debris from door, and place the hanger over the mounting holes. 6. Insert 2 1/4” x 3/8” hex bolts through the strap and door, and loosely attach the washer and nuts. 7. Place a square to the hanger again, and tighten the nuts. *The location of the track is determined by the height of your door. 1. To locate the position of the mounting holes in the wall use the following formula. 2” + (Door Height) = Measurement the lags will enter into the wall 2. PRE-DRILLED TRACK – Hold the track at the previous measurement and mark locations of holes. 3. NO HOLES IN TRACK – At the measured height locate the position of the studs and make a mark. Hold the track above the opening as if installed, and mark the track at the same locations as the studs in the wall. With a 3/8“ drill bit, drill into the track at the markings, including holes on each end for stops if needed. 4. Drill a 1/4” pilot hole at each marking in the wall.

5. With the holes drilled, hold the track up at the determined height, and place the 1 1/ 2″ spacer between the track and the wall. *NOTE – The stops are usually placed on each end of the track. However, they can be placed anywhere along the track to stop the door at a different location than the track’s end. 1. If needed, drill a 3/8″ hole into the track at desired location to ensure door opens fully.car window repair moreno valley ca 2. Select the 1 3/4″ tap bolts and place them through the stop and then the track – use washer and nut to tighten. sliding garage door sydney(You may also use a lag and spacer if the hole location lines up with a stud or if you are going into backing).devon outdoor furniture sale nz

3. The stop can be twisted 180° along the line of the track to either stop the door earlier or later. 4. A rubber track stop pad will be included to soften the slide of the door when the end of track is reached. 1. The bottom door guide includes (1) L-shaped piece of angled steel. 2. For optimal result, cut a 1/4″ groove along the bottom of the door.bi fold door sg 3. Place the guide on the floor with the door closed. sliding shower door plastic clipIt should be on the same side to which the door will slide.glass shower doors delaware 4. Screw the bottom guide into the floor. homelink garage door opener for sale

The guide should be touching the door when the door is fully closed. As the door slides to the side, the guide needs to be in contact with the door at all times. *NOTE: Screws for bottom guide not included. Select depending on the floor material, tile, wood, carpet, etc.If you are in the process of building a barn and looking for good quality barn door hardware, we hope that our door hinges, latches and other hardware willAll of the hardware that we offer has been used on our barns for many years, so you can rest assured you are getting a good quality product. We offer different styles of Door Hinges, Latches and other Barn Hardware to assist you with your barn construction or remodeling project.  both, regular and hand forged style hardware to meet any requirement or need. In addition, we have an access to Cannon Ball hardware and round door tracks for sliding doors. Click on links below to access our on-line catalog.  more hardware in near future
